Superbat SMB Jack (male pin) Straight PCB Through Hole Mount 50 Ohm Connector
Superbat SMB Jack (male pin) Straight PCB Through Hole Mount 50 Ohm Connector
Unit Price: $3.26
sku:S05-SJT15-41BS00A
Real Time Availability
Stock: CONTACT US
Quantity: Units

Series: BNC Termination Type: Terminal Gender: Jack , Female Polarity: Standard Body Style: Straight Impedance: 50 Body Material: Brass Body Plating: Nickel Frequency Range: DC-3GHz

Note: This connector is custom one ,the MOQ is 500 pcs.

The SMB interface features a snap-on coupling mechanism and is available in 50 and 75 ohm configurations. SMB connectors conform to the requirements of MIL-C-39012, and the interface is in compliance with MIL-STD-348.

SMB connectors are available in various materials including an option for die cast components on non-critical areas to provide a low-cost solution.



Features and Benefits

l  Various plating options in nickel, gold, and tin lead

l  Quick connect/disconnect snap on mating reduces installation time

l  SMB PCB slide-on plug and jack allows board-to-board mounting with a low insertion force



Applications

l  Base Stations

l  Antennas

l  Radio Boards

l  PC/LAN

l  Global Positioning System (GPS)

l  Instrumentation

l  Telecommunications
