Main Technical Specification:

Sepcial Type:PV1-F 1*4.00mm2

Rated Voltage:AC0.6/1kV;DC1.8kV

Nominal Cross-sectional Area :4.0mm2

Rated Current :55A

Cable Approx.Odmm:6.3mm

Main Special

Tempeature range of application -40 degree up to 90 degree ,max.tempeature at conductor 120 degree

The permiited short-circult-tempeature refer to a period of 5S is 200 degree.

High resisitance against UV ,ozone and hydrolysis.

Very high machanical robustness and resistence against water ,oil and chemicals.

It is approvalled by TUV.

Notes: This product insulation ,sheath color are black ,also we can have other colors from customers' requires
