The Solar Junction Box, designed for robotic-assembly of silicon photovoltaic systems, reduces assembly time and production costs for PV-panel manufacturers. Rugged and durable, IP67-sealed, DC connectors feature simple snap-lock mating and an internal locking mechanism for superior safety. They are designed for direct connection to solar junction boxes, field installations and PV grid wiring. In addition, DC double-insulated cable assemblies, with proven long life cycle and optimum weather resistance, meet the demands of harsh and outdoor solar wiring applications.
Main technical parameters
Current for PV Module 6.5A
Rated Voltage DC 1000V
Protection Degree IP65
Power Capacity 180W
Touch Protection Class Ⅱ
Temperature Range -40°C ~ 85°C
Diodes Details 3 PCS
Number of terminals 4 rails
Wire Size 4mm² (~10 gauge AWG)
Contact Resistance <5 Ohm
Flame Class UL94-V0
Contact Material Copper
Insulation Material PPO
Standard DIN V VDE 0126-5:2008
Authentication TUV RoHS
Overall dimensions 105*60.5*16mm
1.With the capacity of anti-aging and UV resistant, provide longer life span under outdoor bad condition.
2.Adopted reliable connection solution ,simple,quick and safe effective field assembly.
3. Excellent sealing performance, waterproof and dustproof rating up to IP66.
4 A variety of connectivity options, can provide 2-4 set of input and output wiring, to meet the multi-bypass the need to use high-power Crystalline silicon PV modules.
5 Products for a variety of backplane, with TPT, TPE, and PYE, etc. back to match
6 Products are sold through TUV and RoHS certification, and obtained two patents for utility model and appearance.
7 Patented On PV-JB005
8 A reasonable model of the internal structure and heat dissipation effectively reducing the internal
9 Excellent waterproof and dust effects,，sealed using irrigation methods glue
10 Low-profile,designed with ultra-thin ,structured simple and practical,applicable to 180W crystalline silicon PV modules
11 The connections of Bus-bar and cable were utilized by welding and crimping,electrical performance are safety and reliability.
