Center Frequency 1575.42MHz±3 MHz
V.S.W.R 1.5:1
Band Width±5 MHz
Impedance 50 ohm
Peak Gain ＞3dBic Based on 7×7cm ground plane
Gain Coverage ＞-4dBic at –90°＜0＜+90°(over 75% Volume)
Polarization RHCP
LNA/Filter
LNA Gain (Without cable) 13dB/26dB/28dB/other Typical
Noise Figure 1.5dB
Filter Out Band Attenuation (f0=1575.42 MHZ)
7dB ￡íin f0+/-20MHZ ;
20dB ￡íin f0+/-50MHZ;
30dB ￡íin f0+/-100MHZ
V.S.W.R ＜2.0
DC Voltage 3V , 5V, 3V to 5V or other
DC Current 5mA /11mA/15mA Max
