Model: 3AP-572-N01SJ-070-20
Freq. Range: 800-960/1710-2500 MHz
Gain: 7dBi
V.S.W.R: <=1.5
Horizontal? Beamwidth: 70°
Vertical? Beamwidth: 50°
Nominal Impedance: 50 ohm
Polarization: Vertical
Max Power: 100 W
Connector: N female default

SMA/SSMB/CRC9/TS9/MCX/MMCX/FME/BNC/TNC/SMB/MC-Card/MS-147..and so on.,please give us notes if the other connector is chosen !

Cable length: 20 cm
Temperature: -40 to +140 F
Mounting: 4 hole mounting plate bracket
Size: 207x177x58 mm
Weigh: 600 g
Radome Material: UV Protection ABS
Mounting Way: Wall Mounting
