Technical Specifications
Frequency Range:2.4 GHz
Input Impedance:50 Ohm
V.S.W.R.:<1.5
Gain:16 dBi
Polarization:Vertical, Linear
Max. Input Power:100 W
Connector location:Back
Connector:Standard N Female Connector

Mechanical Specifications
Dimension:260x260x90mm
Weight:Approx. 1.8kg
Radiating   Material:CuAg
Reflector Material:Electrolysis Board
Radom material:ABS
Mounting bracket:120mm x 80mm x 75mm
Horizontal Beamwidth:17 degrees
Vertical Beamwidth:18 degrees
